Amlogic S905X DIY OTT Buildroot Android OpenELEC/Ubuntu/KODI/Dual Boot TV BOX Support GPIOAmlogic S905X DIY OTT Buildroot Android OpenELEC/Ubuntu/KODI/Dual Boot TV BOX Support GPIO

Amlogic S905X DIY OTT Buildroot Android OpenELEC/Ubuntu/KODI/Dual Boot TV BOX Support GPIO

  • Model: Tvi/TVim/TGVim/TVi Lite
  • CPU: Amlogic S905X 2.0 GHz 64Bit Quad Core ARM Cortex-A53 750MHz+
  • OS: Android 6.0
  • GPU: Penta Core Mali-450 GPU
  • LAN: 10/100M
  • DDR3: 1GB/2GB/2GB/1GB
  • EMMC: 8GB/16GB
  • WIFI: AP6212/AP6335/AP6181
  • HDMI CEC: Support
  • USB Type-C: USB2.0 OTG & 5V DC IN
Amlogic S905X DIY OTT Buildroot Android OpenELEC/Ubuntu/KODI/Dual Boot TV BOX Support GPIO

 Product Parameters

Model

TVi

TVim

TGVim

TVi Lite

PCBA Dimensions

82.0 x 57.5 x 11.5 mm

Processor

Amlogic S905X
2.0 GHz 64Bit Quad Core ARM Cortex-A53
750MHz+ Penta Core Mali-450 GPU
HW UHD H.265/VP9 60fps 10bit video decoder
HDR10 and HLG HDR video processing

LAN

10/100M

DDR3 (1866Mbps)

1GB

2GB

2GB

1GB

EMMC V5.0

8GB

8GB

16GB

8GB

WIFI

AP6212

AP6212

AP6335

AP6181

Bluetooth

-

HDMI CEC

-

TVI (Extra Power IN)

-

USB Type-C

USB2.0 OTG & 5V DC IN

HDMI 2.0a

Type-A Female, up to 4K@60Hz

Buttons

x3

x3

x3

x2

USB2.0 HOST

x2

x2

x2

x2

TF Card Slot

RTC & RTC Battery Port

-

IR Receiver

2 Channels

1 Channel

40Pins 2.54mm GPIOs

USB x 2, I2C x 2, UART x 2, SPDIF, PWM, ADC, GPIOs

Mounting Holes

Size M2 x 4

Android 6.0

Ubuntu

-

OpenELEC

-

MOQ

1000

2000



1. very small, only 82.0 x 57.5 x 11.5 mm and compact structure is adopted
2. USB Type-C Slot as power supply, it seems that TVI is the first OTT box using USB Type-C Slot
3. Imported Molex Brand for TF card slot
4. Dual PD Channel Solutions for Infrared Receiver Module (IRM)
5. DDR/EMMC use the original premium brands named SkHynix / Samsung

   ● about the SMD of TVI


1. strictly follow the rules of Electrical Specification, SMD with ESD and Common Mode Choke
2. strictly follow the rules of HDMI 4K Specifications, adopt the independant LDO power module to supply electricity source.
3. PCB with 6 layers for zedoary process. Others usually use 4 layers PCB

   ● about the design of TVI

1. 3 types of Operating system were built, they are Android 6.0, Ubuntu and OpenELEC
2. add the RTC module, realize the memory of time when power off and IoT expansion
3. add independantly MCU module, support the starting-up funtion of device through IRM and Hardware Security Function
4. Support power-on by alarm ( can set the required time to powr-on whenever you need)
5. TVI is of expansibility, our TVI is for OTT+SBC and OTT+IoT, hardware and software open source and technology support. No limited to secondary developers.
6. in the near future, we will develop the 3G/4G module, DVT-T2, Intelligent Housing IoT expansion modules, and other accessories.Amlogic S905X DIY OTT Buildroot Android OpenELEC/Ubuntu/KODI/Dual Boot TV BOX Support GPIO

Tomato Product Advantage

1. Favorable Price
2. Strict Quality Control
3. Software Timely Updates
4. Super Quality (Awesome Software & Qualified Hardware)
5. Fashionable Design& Exquisite Packaging
6. Amazing Performance and Users Experience
7. Portable Mini Size
8. Super Running Speed

Tomato Product Application

1. Smart Home/Hotel System
2. IPTV Solution (OTT, Hybrid Set Top Box)
3. Interactive TV (Hotel, Hospitality)
4. Game Center Box
5. Digital Signage (Outdoor Ads/Indoor Ads)
6. As Medium for Music/Education Resource Content
7. Home Cinema
8. Intelligent Car
9. Video Conference
10. Smart Projector
11. Security Sulution
12. Medical Monitoring/Health Care
13. Intellectual Development

Packaging and Shipping

Shipping Method: DHL, FEDEX, UPS, EMS, TNT, HK Post, China Post etc.
DHL: 3-5 days
Fedex: 3-5 days
UPS: 3-5 days
EMS: 4-7 days
TNT: 5-10 days
HongKong Post: 10-15 days
China Post: 10-20 days

Our Service

Sample service: All samples can be shipped within 24hrs.
Customized service: Mould Design | Board Level Design | Schematic Design | PCB & Mechanical Layout & Design | Package design.
After-sales service: Fully technical support |1 year warranty
(The warranty period starts from the receipt date of products, if these products have any quality problems within this period; the supplier is responsible for maintenance).
You can call us and send us mails directly if any question or problem after sales.

FAQ:

1. What is your OEM/ODM service?
Customized case logo, customized package, customized manual, customized software (booting logo, modifications).
2. What is the delivery time for OEM/ODM order?
20-30 working days after all order details confirmed.
3. How much the courier freight will be for the samples?
Courier freight depends on the quantity, weight and carton size and your area.
4. What's your payment ways?
T/T, Western Union, PayPal
5. Payment terms:
100% payment before shipment for plain orders, If OEM order, 30% deposit before production, 70% balance before shipment.
