Android 6.0.1 tv box support VP9/H.265 up to 4Kx2K@60fps.

  • Model: Android TV Box XBMC
  • 1. Amlogic 905X Kodi16.1
  • 2. Amlogic S905X Quad Core ARM Cortex A53 @2GHz
  • 3. Penta-core Mali-450MP GPU @ 750MHz
  • 4. 8GB EMMC FLASH (16Gb Optional)
  • 5. 1GB DDR3 (2G DDR3 Optional)
  • 6. Android 6.0.1 Lollipop
  • 7. HDMI 2.0 (CEC and HDCP 2.2), 4K*2K @60 fps
  • 8. Support IEEE802.11 b/g/n Bluetooth 4.1EDR
  • 9. 2 High Speed USB 2.0, Support U DISK And USB HDD
  • 10. Ethernet:1000M, Standard RJ45 (optional IEEE 802.3 10/100/1000 Gigabit)
Android 6.0.1 TV Box Support VP9/H.265 up to 4Kx2K@60fps
Android 6.0.1 tv box support VP9/H.265 up to 4Kx2K@60fps.

Hardware

CPU

Amlogic S905X Quad Core ARM Cortex A53 @2GHz

GPU

Penta-core Mali-450MP GPU @ 750MHz,

Memory

DDR31GB (Option: 2GB)

Flash

eMMC8GB  (Option:16GB )

WiFi

IEEE 802.11 b/g/n

Moudle

Plastic : Black  Color

I/O

1*HDMI

4K*2K UHD Output, HDMI 2.0A

1*AV OUT

480i/576i standard definition output

2*USB

1* USB Host Port ,1*USB Device

1*OPTICAL

Digital Audio output

1*RJ45

Ethernet Interface

1*TF CARD

 Support 4GB/8GB/16GB/32GB/64GB

Power

DC 5V/2ALED indicatorWorking Blue; StandbyRed

Software

OS

Android 6.0 Marshmallow

Video

* AMLogic video Engine(AVE)with dedicated hardware decoders and encoders
* Supports multiple "secured"video decoding sessions and simultaneous decoding and encoding
* Video/Picture Decoding
   -VP9 Profile-2 up to 4K*2K@60fps
   -H.265 HEVC MP-10@L5.1 up to 4K*2K@60fps
   -H.264 AVC HP@L5.1 up to 4K*2K@30fps
   -H.264 MVC up to 1080P@60fps
   -MPEG-4 ASP@L5 up to 1080P@60fps(ISO-14496)
   -WMV/VC-1 SP/MP/AP up to 1080P@60fps
   -AVS-P16(AVS+) /AVS-P2 JiZhun Profile up to 1080P@60fps
   -MPEG2 MP/HL up to 1080P@60fps
   -MPEG1 MP/HL up to 1080P@60fps
   -RealVideo 8/9/10 up to 1080P@60fps
* Low latency 1080P H.264 60fps encoder
* HDR10 and HLG HDR Video Processing
* Supports *.mkv,*.mpg,*.wmv,*.mpeg,*.dat,*.avi,*.mov,*.iso,*.mp4,*.rm and *.jpg file formats
* Video/Picture Encoding
   -Independent JPEG and H.264 encoder with configurable performance/bit-rate
   -JPEG image encoding
   -H.264 video encoding up to 1080P@60fps with low latency

Audio

Low power MediaCPU with DSP audio processing
Supports MP3,AAC,WMA,RM,FLAC,Ogg and programmable with 7.1/5.1 down-mixing
Built-in stereo audio DAC
Built-in SPDIF/IEC958 and PCM serial digital audio input/output
Supports concurrent dual audio stereo channel output with combination of analog+PCMo or I2S+PCM


HD JPEGBMPGIFPNGTIF

Language

English French German Spanish Italian etc multilateral languages

Appliactions

Online

Browse all video websites,support Netflix,Hulu,Flixster, Youtube, etc.

Apps

Apps download freely form android marketamazon app store etc.

Medium

Local Media playback,Support HDD, U Disck ,SD/MMC Card .

Talk online

Support  SKYPE video  call ,MSN , facebook ,twitter ,QQ  etc

Others

Support Email,office suit etc.
Support DLNA function
Support 2.4G wireless mouse/keyboard

Features:


Amlogic S905X Quad Core TV Box with lastest Android6.0, Playback VP9 Profile-2 up to 4K*2K@60fps, full suport H.265/H.246.

What's in the box?


1 *Android TV Box XBMC

1 * HDMI Cable

1 * Remote Control

1 * Power Adapter

1 * User Manual
