Google Android5.1 tv box chipset S905 Quad core HDMI2.0 4K S9
- Model: S9
- 1. Google Android5.1 tv box
- 2. Amlogic S905 Quad Core ARM Cortex -A53 CPU up to 2.0 GHz (DVFS)
- 3. Penta-Core Mali-450 Up to 750Mhz +
- 4. 8GB NAND FLASH
- 5. 1GB DDR3
- 6. Android 5.1 Lollipop
- 7. 4K * 2K UHD Output, HDMI 2.0
- 8. Ethernet Interface, 10M / 100M LAN
- 9. Support 4GB / 8GB / 16GB / 32GB / 64GB
- 10. 480i / 576i Standard Definition output
|
Hardware Specifications |
|
|
Model No. |
S9 |
|
CPU |
Amlogic S905 Quad Core ARM Cortex™-A53 CPU up to 2.0 GHz (DVFS) |
|
GPU |
Penta-Core Mali-450 Up to 750Mhz+ |
|
FLASH |
8GB |
|
DDR3 |
1GB DDR3 |
|
Moudle |
Aluminium: Black Color |
|
Power www.sztomato.com |
|
|
Power Supply |
DC 5V/2A |
|
Power Indicator (LED) |
LED indicator, working: Blue, Standby: Red Standby Power: <0.5W |
|
Software |
|
|
OS |
Android™ 5.1 Lollipop |
|
Video |
H.265 HEVC MP-10@L5.1 up to 4Kx2K@60fps |
|
H.264 AVC HP™@L5.1 up to 4Kx2K@30fps |
|
|
H.264 MVC up to 1080P@60fps |
|
|
MPEG-4 ASP@L5 up to 1080P@60fps (ISO-14496) |
|
|
WMV/VC-1 SP/MP/AP up to 1080P@60fps |
|
|
AVS-P16(AVS+) /AVS-P2 Profile up to 1080P@60fps |
|
|
MPEG-2 MP/HL up to 1080P@60fps (ISO-13818) |
|
|
MPEG-1 MP/HL up to 1080P@60fps (ISO-11172) |
|
|
RealVideo 8/9/10 up to 1080P |
|
|
WebM up to VGA |
|
|
Multiple Language and Multiple Format Sub-title Video Support |
|
|
MJPEG and JPEG Unlimited Pixel Resolution Decoding(ISO/IEC-10918) |
|
|
Supports JPEG Thumbnail, Scaling, Rotation and Transition effects |
|
|
Supports *.mkv,*.wmv,*.mpg, *.mpeg, *.dat, *.avi, *.mov, *.iso, *.mp4, *.rm and *.jpg file Formats |
|
|
Audio |
Low Power MediaCPU with DSP Audio Processing |
|
Supports MP3, AAC, WMA, RM, FLAC, Ogg and Programmable with 5.1 down-mixing |
|
|
Built-in SPDIF/IEC958 and PCM Serial Digital Audio input/output |
|
|
Image |
HD JPEG, BMP, GIF, PNG, TIF |
|
Support language |
Chinese, English, Germany, Japanese, Korea etc. Multi languages |
|
I/O www.sztomato.com |
|
|
1*HDMI™ |
4K*2K UHD Output, HDMI™ 2.0 |
|
1*AV OUT |
480i/576i Standard Definition output |
|
3*USB |
2*USBHost Port , 1*USB Device |
|
1*OPTICAL |
Digital Audio output |
|
1*RJ45 |
Ethernet Interface, 1000M LAN |
|
1*SD™/MMC CARD |
Support 4GB/8GB/16GB/32GB/64GB |
|
Appliactions |
|
|
Online |
Browse all video websites, support Netflix, Hulu, Flixster, Youtube, etc. |
|
Apps |
Apps download freely form android market, amazon™ app store etc. |
|
Medium |
Local Media playback, Support HDD, U Disck, SD™/MMC Card. |
|
Talk Online |
Support SKYPE video call, MSN, facebook, twitter, QQ etc. |
|
Others |
Support Email, Office Suit etc. Support DLNA Function Support 2.4G Wireless Mouse/Keyboard |
