Smart Android TV Box Android Smart TV BoxSmart Android TV Box Android Smart TV BoxSmart Android TV Box Android Smart TV Box

Smart Android TV Box Android Smart TV Box

  • Model No.: Rockchip RK3588 Android Smart TV Box
  • CPU: Rockchip RK3588 8nm process, quad-core Cortex-A76 + quad-core Cortex-A55
  • GPU: ARM Mali-G610 MC4 OpenGL ES 1.1/2.0/3.1/3.2 Vulkan 1.1, 1.2 OpenCL 1.1,1.2,2.0 Embedded high performance 2D image acceleration module
  • NPU:6TOPS NPU, triple core, support int4/int8/int16/FP16/BF16/TF32 acceleration

Smart Android TV Box Android Smart TV Box

Smart Android TV Box Android Smart TV Box

Specifications

Model No.

Rockchip RK3588

CPU

Rockchip RK3588 8nm process, quad-core Cortex-A76 + quad-core Cortex-A55

GPU

ARM Mali-G610 MC4 OpenGL ES 1.1/2.0/3.1/3.2 Vulkan 1.1, 1.2 OpenCL 1.1,1.2,2.0 Embedded high performance 2D image acceleration module

NPU

6 TOPS (Supports int4/int8/int16/FP16/BF16/TF32)

RAM

4GB/8GB (64bit LPDDR4/LPDDR4x)

ROM

32G/64G/128G/256G (eMMC5.0/ 5.1)

WiFi

Type

IEEE 802.11a/b/g/n/ac/ax

Frequency

Wi-Fi6 2.4GHz/5.8GHz ( PCIe v3.0)

Antenna Type

2T2R

OS

Android 12 and Multi-Language

Bluetooth

Bluetooth 5.0

Video&Audio CODEC

Video Codec

Real-time video decoder of MPEG-1,MPEG-2,MPEG-4,H.263,H.264,H.265,VC-1,VP9,VP8 MVC,AV1

MMU Embedded

Multi-channel decoder in parallel for less resolution

H.264 AVC/MVC Main10 L6.0 : 8K@30fps (7680x4320)

VP9 Profile0/2 L6.1 : 8K@60fps (7680x4320)

H.265 HEVC/MVC Main10 L6.1 : 8K@60fps (7680x4320)

AVS2 Profile0/2 L10.2.6 : 8K@60fps (7680x4320)

AV1 Main Profile 8/10bit L5.3 : 4K@60fps (3840x2160)

MPEG-2 up to MP : 1080p@60fps (1920x1088)

MPEG-1 up to MP : 1080p@60fps (1920x1088)

VC-1 up to AP level 3 : 1080p@60fps (1920x1088)

VP8 version2 : 1080p@60fps (1920x1088)

Video Encoder

Real-time H.265/H.264 video encoding

Support up to 8K@30fps

Multi-channel encoder in parallel for less resolution

Dual 16M Pixel ISP with HDR&3DNR

Audio Codec

I2S0 with 8 channels

Up to 8 channels TX and 8 channels RX path

Audio resolution from 16bits to 32bits

Sample rate up to 192KHz

Provides master and slave work mode, software configurable

Support 3 I2S formats (normal, left-justified, right-justified)

Support 4 PCM formats (early, late1, late2, late3)

Support TDM normal, 1/2 cycle left shift, 1 cycle left shift, 2 cycle left shift, right shift mode serial audio data transfer

I2S, PCM and TDM mode cannot be used at the same time

I/O Port

Power Supply

DC 12V/2A Power ON: Blue

RTC

Support

IR

Infrared + BT Voice Remote

HDMI

HDMI OUT 1:HDMI 2.1/7680x4320@60Hz

HDMI OUT 2:HDMI 2.1/4096x2304@60Hz

HDMI IN:HDMI 2.0/HDMI 1.4b 4K x 2K video formats(3840x 2160p@24Hz/25Hz/30Hz and 4096x2160p@24Hz)

Earphone

1*3.5mm Port

Ethernet

Ethernet 1:1*1000M(RGMII)

Ethernet 2:1*1000M

TF Card

1*TF Card

USB port

2*USB 2.0 (Host)

1*USB3.0 (Host)

Type-C

1*Type C 3.0 (Download Port) Supported Devices















Smart Android TV Box Android Smart TV BoxSmart Android TV Box Android Smart TV BoxSmart Android TV Box Android Smart TV BoxSmart Android TV Box Android Smart TV BoxSmart Android TV Box Android Smart TV BoxAndroid Smart TV Box OEM Internet TV BOX SupplierSmart Android TV Box Android Smart TV Box

Our Smart Android TV Box is designed to revolutionize your entertainment experience with its advanced features and seamless performance. Whether you're streaming your favorite movies and TV shows or diving into immersive gaming sessions, this device delivers exceptional quality and convenience.

At the heart of this TV box is its smart functionality, powered by the Android operating system. This gives you access to a vast array of apps, games, and content through the Google Play Store, allowing you to customize your entertainment experience to suit your preferences.

The device is equipped with powerful hardware, ensuring smooth and seamless streaming of high-definition content. Whether you're watching movies in 4K resolution or playing graphics-intensive games, every detail is rendered with clarity and precision, providing an immersive viewing or gaming experience.

Connectivity options are comprehensive, with built-in Wi-Fi and Ethernet support ensuring stable and fast internet connections. This is crucial for uninterrupted streaming and online gaming, without any buffering or lag issues. Multiple USB ports and expandable storage options offer flexibility for connecting peripherals and storing media files.

The TV box also features HDMI connectivity, allowing you to connect to a wide range of display devices, including TVs, monitors, and projectors. This versatility ensures compatibility with your existing setup, enhancing convenience and ease of use.

Audio quality is equally impressive, with support for advanced audio technologies like Dolby Audio. Whether you're using built-in speakers or connecting to a surround sound system, you'll enjoy immersive and lifelike audio that complements the visuals for a truly cinematic experience.

The user interface is designed to be intuitive and user-friendly, making navigation effortless. From setting up the device to browsing through apps and adjusting settings, everything is streamlined for a smooth and enjoyable user experience.

In summary, our Smart Android TV Box combines advanced features, seamless performance, and user-friendly design to deliver an unparalleled entertainment experience. Whether you're a casual viewer, a gaming enthusiast, or a multimedia user, this TV box is sure to elevate your entertainment to new heights.
