Allwinner H616 Quad Core Android 10 TV BoxAllwinner H616 Quad Core Android 10 TV BoxAllwinner H616 Quad Core Android 10 TV BoxAllwinner H616 Quad Core Android 10 TV BoxAllwinner H616 Quad Core Android 10 TV BoxAllwinner H616 Quad Core Android 10 TV BoxAllwinner H616 Quad Core Android 10 TV BoxAllwinner H616 Quad Core Android 10 TV BoxAllwinner H616 Quad Core Android 10 TV Box

Allwinner H616 Quad Core Android 10 TV Box

  • Model No.: X96Q MAX
  • CPU: Allwinner H616 Quad Core ARM Cortex A53
  • GPU: G31 MP2
  • RAM: DDR3: 4GB
  • Internal Storage: eMMC: 32GB(Option:64GB)
  • OS: Android 10.0
  • WiFi: IEEE 802.11 b/g/n/ac
Allwinner H616 Quad Core Android 10 TV Box


Specifications

Model No.

X96Q MAX

CPU

Allwinner H616 Quad Core ARM Cortex A53

GPU

G31 MP2

RAM

DDR3: 4GB

Internal Storage

eMMC: 32GB(Option:64GB)

OS

Android 10.0

WiFi

IEEE 802.11 b/g/n/ac

Video&Audio CODEC

Video

Video Engine (AVE) with dedicated hardware decoders and encoders

Support multi-video decoder up to 4Kx2K@60fps+1x1080P@60fps

Supports multiple “secured” video decoding sessions and simultaneous decoding and encoding

Video Decoding

-  VP9 Profile 2 up to 4Kx2K@60fps

-  H.265 Main10@L5.1 up to 4Kx2K@60fps,or 6K@30fps

-  AVS2-P2 Profile up to 4Kx2K@60fps

-  H.264 BP/MP/HP@L4.2 up to 4Kx2K@30fps

-  H.263 BP up to 1080P@60fps

-  MPEG-4 SP/ASP@L5 up to 1080P@60fps (ISO-14496)

-  MPEG-2 MP/HL up to 1080P@60fps (ISO-13818)

-  MPEG-1 MP/HL up to 1080P@60fps (ISO-11172)

-  Xvid up to 1080P@60fps

-  Sorenson Spark up to 1080P@60fps

-  VP8 up to 1080P@60fps

-  AVS/AVS+ JiZhun Profile up to 1080P@60fps

-  WMV9/VC1 SP/MP/AP up to 1080P@60fps

-  JPEG HFIF file format up to 45MPPS

-  Multiple language and multiple format sub-title video support

-  MJPEG and JPEG unlimited pixel resolution decoding (ISO/IEC-10918)

-  Supports JPEG thumbnail, scaling, rotation and transition effects

-  Supports *.mkv,*.wmv,*.mpg, *.mpeg, *.dat, *.avi, *.mov, *.iso, *.mp4, *.rm and *.jpg file formats

Audio

Supports MP3, AAC, WMA, RM, FLAC, Ogg and programmable with 7.1/5.1 down-mixing

Audio Codec

-Two audiio digital-to-analog(DAC) channels

-Support 16-bit and 20-bit sample rate

-8kHz to 192kHz DAC sample rate

-95+/-2dB SNR@A-weight,-80+/-dB THD+N,output Level more than 0.55Vrms

-One128*24-bits FIFO for DAC data transmit

built-in TDM/PCM/I2S ports with TDM/PCM mode up to 384kHz x32bits x 8ch or 96kHz x 32bits x 32ch and I2S mode up to 384kHz x 32bits x 8ch

Digital microphone PDM input with programmable CIC, LPF & HPF, support up to 8 DMICs

Built-in stereo audio DAC

Supports concurrent dual audio stereo channel output with combination of analog+PCM or I2S+PCM

I/O

1*HDMI

4K*2K UHD Output, HDMI 2.0A

1*AV OUT

480i/576i standard definition output

3*USB

3*USB 2.0

1*IR Reciver

Remote Reciver Connect

1*RJ45

Ethernet Interface

1*TF CARD

Support 4GB/8GB/16GB/32GB/64GB

Power

DC 5V/2ALED indicator. Working: blue

Others


HD JPEG, BMP, GIF, PNG, TIF

Language

English French German Spanish Italian etc multilateral languages

Option

Browse all video websites, support Netflix,Hulu,Flixster,Youtube, etc.

Apps download freely form android market, amazon app store etc.

Local Media playback, Support HDD, U Disck , TF Card.
