TV Box Android 4K Android 14 TV SticksTV Box Android 4K Android 14 TV SticksTV Box Android 4K Android 14 TV SticksTV Box Android 4K Android 14 TV SticksTV Box Android 4K Android 14 TV SticksTV Box Android 4K Android 14 TV SticksTV Box Android 4K Android 14 TV SticksTV Box Android 4K Android 14 TV Sticks

TV Box Android 4K Android 14 TV Sticks

  • Model No.: Amlogic S905X5M TV Box Android
  • CPU: Amlogic S905X5M Quad Core ARM Cortex A55
  • GPU: ARM G310 V2 OpenGL ES 3.2, Vulkan 1.2 and OpenCL 2.0 support
  • RAM: 4GB (2GB/4GB Optional)
  • ROM: 64GB (16GB/32GB/64GB/128GB Optional)
  • OS: Android 14 Multi-Language
  • WiFi: Support 2.4G and 5.8G, Support WiFi IEEE 802.11 a/ b / g / n /ac/ax
  • Bluetooth: Support BT5.X

TV Box Android 4K Android 14 TV Sticks

 Specifications

Model No.

Amlogic S905X5M TV Box Android

CPU

Amlogic S905X5M Quad Core ARM Cortex A55

GPU

ARM G310 V2 OpenGL ES 3.2, Vulkan 1.2 and OpenCL 2.0 support

RAM

4GB (2GB/4GB Optional)

ROM

64GB (16GB/32GB/64GB/128GB Optional)

OS

Android 14 Multi-Language

WiFi

Support 2.4G and 5.8G, Support WiFi IEEE 802.11 a/ b / g / n /ac/ax

Bluetooth

Support BT5.X

 Video&Audio CODEC

Multimedia

AV1 MP-10@L5.1 up to 4Kx2K@60fps

VP9 Profile-2 up to 4Kx2K@60fps

H.265 HEVC MP-10@L5.1 up to 4Kx2K@60fps

MPEG-4 ASP@L5 up to 1080P@60fps (ISO-14496)

WMV/VC-1 SP/MP/AP up to 1080P@60fps

AVS-P16(AVS+) /AVS-P2 JiZhun Profile up to 1080P@60fps

MPEG-2 MP/HL up to 1080P@60fps (ISO-13818)

MPEG-1 MP/HL up to 1080P@60fps (ISO-11172)

Multiple language and multiple format sub-title video support

MJPEG and JPEG unlimited pixel resolution decoding (ISO/IEC-10918)

Supports JPEG thumbnail, scaling, rotation and transition effects

Supports *.mkv,*.wmv,*.mpg, *.mpeg, *.dat, *.avi, *.mov, *.iso, *.mp4, *.rm and *.jpg file formats

Supports HDR10, HDR10+ processing

Inline AI-SR,Block noise, mosquito noise, spatial noise, contour noise reduction

Audio

Supports MP3, AAC, WMA, RM, FLAC, Ogg

 I/O

1*HDMI

4K*2K UHD Output

1*Type C

1*Type-c

2*USB

2*USB A 2.0 Normal

RJ45

Not Support

1*TF Card

Support

Power

DC IN(5V/2A)

Others


HD JPEG, BMP, GIF, PNG, TIF

Option

Browse all video websites, support Netflix, Hulu, Flixster, Youtube, etc.

Apps download freely form android market, amazon app store etc.


TV Box Android 4K Android 14 TV Sticks – Amlogic S905X5M Quad-Core, AI-SR, Wi-Fi 6 & HDR10+TV Box Android 4K Android 14 TV Sticks – Amlogic S905X5M Quad-Core, AI-SR, Wi-Fi 6 & HDR10+TV Box Android 4K Android 14 TV Sticks – Amlogic S905X5M Quad-Core, AI-SR, Wi-Fi 6 & HDR10+TV Box Android 4K Android 14 TV Sticks – Amlogic S905X5M Quad-Core, AI-SR, Wi-Fi 6 & HDR10+TV Box Android 4K Android 14 TV Sticks – Amlogic S905X5M Quad-Core, AI-SR, Wi-Fi 6 & HDR10+TV Box Android 4K Android 14 TV Sticks – Amlogic S905X5M Quad-Core, AI-SR, Wi-Fi 6 & HDR10+TV Box Android 4K Android 14 TV Sticks – Amlogic S905X5M Quad-Core, AI-SR, Wi-Fi 6 & HDR10+TV Box Android 4K Android 14 TV Sticks – Amlogic S905X5M Quad-Core, AI-SR, Wi-Fi 6 & HDR10+TV Box Android 4K Android 14 TV Sticks – Amlogic S905X5M Quad-Core, AI-SR, Wi-Fi 6 & HDR10+TV Box Android 4K Android 14 TV Sticks – Amlogic S905X5M Quad-Core, AI-SR, Wi-Fi 6 & HDR10+TV Box Android 4K Android 14 TV Sticks – Amlogic S905X5M Quad-Core, AI-SR, Wi-Fi 6 & HDR10+TV Box Android 4K Android 14 TV Sticks – Amlogic S905X5M Quad-Core, AI-SR, Wi-Fi 6 & HDR10+TV Box Android 4K Android 14 TV Sticks – Amlogic S905X5M Quad-Core, AI-SR, Wi-Fi 6 & HDR10+

Key Features

  • Quad‑Core Cortex‑A55 CPU at 2.5 GHz
    Delivers roughly 30 K DMIPS for responsive UI, multitasking and app launches on Android 14.

  • Arm Mali‑G310 V2 GPU
    Supports OpenGL ES 3.2, Vulkan 1.2 and OpenCL 2.0 for smooth graphics, casual gaming and hardware‑accelerated 4K video decoding (AV1/VP9/H.265).

  • Inline AI‑SR (AISR2) Upscaling
    Real‑time AI‑driven super‑resolution sharpens legacy HD and Full HD streams to near‑4K without stutter or added latency.

  • HDR10+ Video Processing
    Dynamic metadata–driven contrast enhancements render deeper blacks and more vibrant highlights in movies and sports.

  • Dual‑Band Wi‑Fi 6 & Bluetooth 5.x
    Ensures robust 802.11ax throughput for 4K@60 fps streaming and near‑instant pairing of controllers, keyboards or audio devices.

  • Flexible RAM & Storage
    Choose 2 GB or 4 GB LPDDR4X RAM and 16 GB–128 GB eMMC, expandable via two USB A ports and a microSD slot for media libraries or peripherals.

  • Compact USB‑C Stick Form Factor
    Plugs directly into HDMI 2.1 ports, drawing under 5 W peak power and operating silently—ideal for discreet installs behind TVs or projectors.

The TV Box Android 4K Android 14 TV Sticks – powered by the Amlogic S905X5M Quad-Core AI-SR SoC in a sleek, USB-C form factor. Designed to transform any display into a smart entertainment hub, this compact stick delivers blazing-fast performance, crystal-clear 4K×2K output, and intelligent AI upscaling, all running the latest Android 14 for a seamless, modern user experience.

At its heart lies the energy-efficient 6 nm Amlogic S905X5M processor with four ARM Cortex-A55 cores clocked at up to 2.5 GHz, delivering roughly 30 000 DMIPS. Whether you’re launching multiple apps, switching between streaming services, or browsing the web, everything feels instant and responsive. The integrated Arm Mali-G310 V2 GPU accelerates high-definition video decoding and casual gaming, supporting OpenGL ES 3.2, Vulkan 1.2, and OpenCL 2.0 for smooth UI animations, rich graphical interfaces, and fluid frame rates.

Enjoy native AV1, VP9, and H.265/HEVC decoding up to 4K*2K@60 fps with HDR10+ and HLG support, bringing greater contrast and lifelike color to movies, sports, and games. The HDMI 2.1 output ensures compatibility with the latest 4K displays and TVs, delivering true-to-life visuals at up to 60 Hz. An onboard Inline AI-SR engine intelligently analyzes incoming video frames in real time, upscaling lower-resolution streams to near-4K clarity without added latency or artifacts. Legacy HD content, user-generated videos, and live streams all gain sharper outlines and richer textures.

Running Android 14, the TV stick offers the refreshed Material You interface with dynamic, AI-generated wallpapers that adapt to your style. Granular privacy controls let you grant one-time or limited-time access to camera, microphone, and location, keeping your data secure. Accessibility enhancements include customizable font scaling, high-contrast text, and visual flash notifications, making the device suitable for all audiences. Full access to the Google Play Store enables installation of favorite streaming apps, games, productivity tools, and smart-home controllers.

Connectivity is rock solid with dual-band Wi-Fi 6 (802.11ax) and Bluetooth 5.x support. Wi-Fi 6’s OFDMA and MU-MIMO technologies boost network efficiency in congested environments, ensuring uninterrupted 4K streaming and low-latency gaming. Bluetooth 5.x pairs instantly with keyboards, controllers, headphones, and speakers, while two USB A ports and a USB C power port allow connection of external storage, peripherals, and power delivery through standard adapters. A microSD slot provides expandable storage for media libraries, office documents, or signage playlists.

Memory and storage options are flexible to match every need: choose 4 GB LPDDR4X RAM and 16 GB, 32 GB, 64 GB, or 128 GB eMMC storage. This scalability ensures smooth multitasking, quick app launches, and ample space for downloaded videos, applications, and user data. Despite its small footprint, the TV stick delivers robust processing power normally found in larger set-top boxes or mini-PCs.

Designed for universal appeal, the device supports multi-language menus and subtitles across a wide range of formats, including MKV, MP4, AVI, and MOV. Out-of-the-box compatibility with Netflix, YouTube, Hulu, and other popular streaming services means instant access to entertainment. For business and signage applications, the stick can host digital menu boards, interactive kiosks, or informational displays, all powered by the same versatile hardware and Android platform.

With its combination of cutting-edge AI upscaling, powerful quad-core CPU, modern GPU capabilities, and comprehensive connectivity, the TV Box Android 4K Android 14 TV Sticks redefine the standard for Android TV sticks. Whether for home entertainment, corporate signage, or portable computing, this device offers future-proof performance in an ultra-portable package.
